Purified Water Distribution System for PW / WFI

We are remarkable manufacturers of Purified Water Distribution Systems catering the needs of our esteemed clientele. Our offered Purified Water Distribution Systems are required for optimum distribution of purified water in various industrial processes. These offered Purified Water Distribution Systems are very much required for efficient distribution of purified water with accurate and precision at critical applications in accordance to our valuable clientele.

Our offered Purified Water Distribution Systems are appreciated for their efficiency, corrosion resistant, durability, easy operation and easy maintenance, thus makes us as ultimate choice as Purified Water Distribution Systems manufacturers in India to our esteemed clientele. This offered Purified Water Distribution Systems are manufactured with state of art facility under the supervision of experts. Quality control is our top priority and ensures that all our offered Purified Water Distribution Systems passed laid quality checking procedures. We are offering finest quality Purified Water Distribution Systems at competitive prices available in the market.

Storage and distribution system is required to store and distribute PW and WFI water to various user points and in a closed loop system. Distribution system is used in Pharmaceutical, Biotech and Food industries.

• Purified water and WFI storage tanks is designed and manufactured as per cGMP or ASME SEC VIII DIV 1 standard.
• Storage tank can be plain, steam jacketed, electrically heated, Limpetted tanks which are provided with Rockwool / Glasswool with AISI SS304 cladding.
• PW /WFI tanks are provided with necessary accessories.
• Fully drainable and required flow sanitary pumps are sleceted in order to achieve the return line velocity of 1.2m/sec.
• Distribution skid is provided with necessary pumps, instruments like Flow, Conductivity and TOC count and UV disinfectant system and PLC based control panel.
• Two Pumps (1 Working and 1 Standby) are provided to ensure continuous hassle free operation along with swing arm assembly for easy changeover and incorporated with Variable frequency drive so as to minimize the ppower requirement and also to maintain the velocity.
• Online shell and Tube heat exchangers
• SS pendants with provision for PW, Air, Potable water, Steam etc.
• The distribution system is designed for 100% drainablility by maintaining rhe the sloop of 1:100
• PLC and SCADA based system with online printing facility to achieve compliance with 21 CFR PART 11 and GAMP 5 so less human interferance and low maintenance required.
• SS316L piping with internally electropolished and outside mirror finished is used in distribution loop system having sterile zero dead leg draw off valves.
• Core Features & Characteristics of the system like crevices & dead leg free design, 0.4µ RA finish from inside & outside 0.8 µ ; complete drain ability; Non– Contact MoC -304 out side matt finish to 0.8 ra; completely suitable for in-line CIP options & Sanitization with complete records if required.
• All inter connecting piping is done by orbital welding with high purity argon gas and welding joints can be iinspected with Boroscopy machine.
• Complete set of Documentation like DQ, IQ, OQ, FAT, SAT with certificates and also assist client to develop PQ to achieve compliance with necessary regulatory authority.
